Inheritance diagram for com.google.appinventor.components.runtime.AccelerometerSensor:

Public Member Functions
	AccelerometerSensor (ComponentContainer container)

int	MinimumInterval ()

void	MinimumInterval (int interval)

int	Sensitivity ()

void	Sensitivity (int sensitivity)

void	AccelerationChanged (float xAccel, float yAccel, float zAccel)

int	getDeviceDefaultOrientation ()

void	Shaking ()

boolean	Available ()

boolean	Enabled ()

void	Enabled (boolean enabled)

float	XAccel ()

float	YAccel ()

float	ZAccel ()

void	LegacyMode (boolean legacyMode)

boolean	LegacyMode ()

void	onSensorChanged (SensorEvent sensorEvent)

void	onAccuracyChanged (Sensor sensor, int accuracy)

void	onResume ()

void	onPause ()

void	onDelete ()

Public Member Functions inherited from com.google.appinventor.components.runtime.AndroidNonvisibleComponent
HandlesEventDispatching	getDispatchDelegate ()

Additional Inherited Members
Static Public Attributes inherited from com.google.appinventor.components.runtime.Component
static final String	ASSET_DIRECTORY = "component"

static final int	ALIGNMENT_NORMAL = 0

static final int	ALIGNMENT_CENTER = 1

static final int	ALIGNMENT_OPPOSITE = 2

static final int	ACCELEROMETER_SENSITIVITY_WEAK = 1

static final int	ACCELEROMETER_SENSITIVITY_MODERATE = 2

static final int	ACCELEROMETER_SENSITIVITY_STRONG = 3

static final int	BUTTON_SHAPE_DEFAULT = 0

static final int	BUTTON_SHAPE_ROUNDED = 1

static final int	BUTTON_SHAPE_RECT = 2

static final int	BUTTON_SHAPE_OVAL = 3

static final int	COLOR_NONE = 0x00FFFFFF

static final int	COLOR_BLACK = 0xFF000000

static final int	COLOR_BLUE = 0xFF0000FF

static final int	COLOR_CYAN = 0xFF00FFFF

static final int	COLOR_DKGRAY = 0xFF444444

static final int	COLOR_GRAY = 0xFF888888

static final int	COLOR_GREEN = 0xFF00FF00

static final int	COLOR_LTGRAY = 0xFFCCCCCC

static final int	COLOR_MAGENTA = 0xFFFF00FF

static final int	COLOR_ORANGE = 0xFFFFC800

static final int	COLOR_PINK = 0xFFFFAFAF

static final int	COLOR_RED = 0xFFFF0000

static final int	COLOR_WHITE = 0xFFFFFFFF

static final int	COLOR_YELLOW = 0xFFFFFF00

static final int	COLOR_DEFAULT = 0x00000000

static final String	DEFAULT_VALUE_COLOR_NONE = "&H00FFFFFF"

static final String	DEFAULT_VALUE_COLOR_BLACK = "&HFF000000"

static final String	DEFAULT_VALUE_COLOR_BLUE = "&HFF0000FF"

static final String	DEFAULT_VALUE_COLOR_CYAN = "&HFF00FFFF"

static final String	DEFAULT_VALUE_COLOR_DKGRAY = "&HFF444444"

static final String	DEFAULT_VALUE_COLOR_GRAY = "&HFF888888"

static final String	DEFAULT_VALUE_COLOR_GREEN = "&HFF00FF00"

static final String	DEFAULT_VALUE_COLOR_LTGRAY = "&HFFCCCCCC"

static final String	DEFAULT_VALUE_COLOR_MAGENTA = "&HFFFF00FF"

static final String	DEFAULT_VALUE_COLOR_ORANGE = "&HFFFFC800"

static final String	DEFAULT_VALUE_COLOR_PINK = "&HFFFFAFAF"

static final String	DEFAULT_VALUE_COLOR_RED = "&HFFFF0000"

static final String	DEFAULT_VALUE_COLOR_WHITE = "&HFFFFFFFF"

static final String	DEFAULT_VALUE_COLOR_YELLOW = "&HFFFFFF00"

static final String	DEFAULT_VALUE_COLOR_DEFAULT = "&H00000000"

static final float	FONT_DEFAULT_SIZE = 14

static final int	LAYOUT_ORIENTATION_HORIZONTAL = ComponentConstants.LAYOUT_ORIENTATION_HORIZONTAL

static final int	LAYOUT_ORIENTATION_VERTICAL = ComponentConstants.LAYOUT_ORIENTATION_VERTICAL

static final int	SCALING_SCALE_PROPORTIONALLY = 0

static final int	SCALING_SCALE_TO_FIT = 1

static final int	TYPEFACE_DEFAULT = 0

static final int	TYPEFACE_SANSSERIF = 1

static final int	TYPEFACE_SERIF = 2

static final int	TYPEFACE_MONOSPACE = 3

static final int	LENGTH_PREFERRED = -1

static final int	LENGTH_FILL_PARENT = -2

static final int	LENGTH_UNKNOWN = -3

static final int	LENGTH_PERCENT_TAG = -1000

static final int	TOAST_LENGTH_SHORT = 0

static final int	TOAST_LENGTH_LONG = 1

static final int	DIRECTION_NORTH = 1

static final int	DIRECTION_NORTHEAST = 2

static final int	DIRECTION_EAST = 3

static final int	DIRECTION_SOUTHEAST = 4

static final int	DIRECTION_SOUTH = -1

static final int	DIRECTION_SOUTHWEST = -2

static final int	DIRECTION_WEST = -3

static final int	DIRECTION_NORTHWEST = -4

static final int	DIRECTION_NONE = 0

static final int	DIRECTION_MIN = -4

static final int	DIRECTION_MAX = 4

static float	SLIDER_MIN_VALUE = 10

static float	SLIDER_MAX_VALUE = 50

static float	SLIDER_THUMB_VALUE = (SLIDER_MIN_VALUE + SLIDER_MAX_VALUE) / 2.0f

static final String	DEFAULT_VALUE_TEXT_TO_SPEECH_COUNTRY = ""

static final String	DEFAULT_VALUE_TEXT_TO_SPEECH_LANGUAGE = ""

Protected Member Functions inherited from com.google.appinventor.components.runtime.AndroidNonvisibleComponent
	AndroidNonvisibleComponent (Form form)

Protected Attributes inherited from com.google.appinventor.components.runtime.AndroidNonvisibleComponent
final Form	form

Detailed Description

Non-visible component that can detect shaking and measure acceleration approximately in three dimensions using SI units (m/s²). The components are:

xAccel: 0 when the phone is at rest on a flat surface, positive when the phone is tilted to the right (i.e., its left side is raised), and negative when the phone is tilted to the left (i.e., its right size is raised).
yAccel: 0 when the phone is at rest on a flat surface, positive when its bottom is raised, and negative when its top is raised.
zAccel: Equal to -9.8 (earth's gravity in meters per second per second when the device is at rest parallel to the ground with the display facing up, 0 when perpendicular to the ground, and +9.8 when facing down. The value can also be affected by accelerating it with or against gravity.

@internaldoc Physical world component that can detect shaking and measure acceleration in three dimensions. It is implemented using android.hardware.SensorListener (http://developer.android.com/reference/android/hardware/SensorListener.html).

From the Android documentation: "Sensor values are acceleration in the X, Y and Z axis, where the X axis has positive direction toward the right side of the device, the Y axis has positive direction toward the top of the device and the Z axis has positive direction toward the front of the device. The direction of the force of gravity is indicated by acceleration values in the X, Y and Z axes. The typical case where the device is flat relative to the surface of the Earth appears as -STANDARD_GRAVITY in the Z axis and X and Y values close to zero. Acceleration values are given in SI units (m/s^2)."

Definition at line 91 of file AccelerometerSensor.java.

Constructor & Destructor Documentation

◆ AccelerometerSensor()

com.google.appinventor.components.runtime.AccelerometerSensor.AccelerometerSensor ( ComponentContainer container )

Creates a new AccelerometerSensor component.

Parameters

container ignored (because this is a non-visible component)

Definition at line 145 of file AccelerometerSensor.java.

Member Function Documentation

◆ AccelerationChanged()

void com.google.appinventor.components.runtime.AccelerometerSensor.AccelerationChanged	(	float	xAccel,
		float	yAccel,
		float	zAccel
	)

Indicates the acceleration changed in the X, Y, and/or Z dimensions.

Definition at line 232 of file AccelerometerSensor.java.

◆ Available()

boolean com.google.appinventor.components.runtime.AccelerometerSensor.Available ( )

Returns whether the AccelerometerSensor hardware is available on the device.

Returns: true

indicates that an accelerometer sensor is available,
false

that it isn't

Definition at line 295 of file AccelerometerSensor.java.

◆ Enabled() [1/2]

boolean com.google.appinventor.components.runtime.AccelerometerSensor.Enabled ( )

If true, the sensor will generate events. Otherwise, no events are generated even if the device is accelerated or shaken.

Returns: true

indicates that the sensor generates events,
false

that it doesn't

Definition at line 309 of file AccelerometerSensor.java.

◆ Enabled() [2/2]

void com.google.appinventor.components.runtime.AccelerometerSensor.Enabled ( boolean enabled )

Specifies whether the sensor should generate events. If true{:.logic.block}, the sensor will generate events. Otherwise, no events are generated even if the device is accelerated or shaken.

Parameters

enabled

Definition at line 347 of file AccelerometerSensor.java.

◆ getDeviceDefaultOrientation()

int com.google.appinventor.components.runtime.AccelerometerSensor.getDeviceDefaultOrientation ( )

Definition at line 254 of file AccelerometerSensor.java.

◆ LegacyMode() [1/2]

boolean com.google.appinventor.components.runtime.AccelerometerSensor.LegacyMode ( )

Definition at line 449 of file AccelerometerSensor.java.

◆ LegacyMode() [2/2]

void com.google.appinventor.components.runtime.AccelerometerSensor.LegacyMode ( boolean legacyMode )

Definition at line 445 of file AccelerometerSensor.java.

◆ MinimumInterval() [1/2]

int com.google.appinventor.components.runtime.AccelerometerSensor.MinimumInterval ( )

Returns the minimum interval required between calls to Shaking(), in milliseconds. Once the phone starts being shaken, all further Shaking() calls will be ignored until the interval has elapsed.

Returns: minimum interval in ms

Definition at line 172 of file AccelerometerSensor.java.

◆ MinimumInterval() [2/2]

void com.google.appinventor.components.runtime.AccelerometerSensor.MinimumInterval ( int interval )

Specifies the minimum interval required between back-to-back Shaking() events, in milliseconds. Once the phone starts being shaken, all further Shaking() events will be ignored until the interval has elapsed.

Parameters

interval minimum interval in ms

Definition at line 186 of file AccelerometerSensor.java.

◆ onAccuracyChanged()

void com.google.appinventor.components.runtime.AccelerometerSensor.onAccuracyChanged	(	Sensor	sensor,
		int	accuracy
	)

Definition at line 475 of file AccelerometerSensor.java.

◆ onDelete()

void com.google.appinventor.components.runtime.AccelerometerSensor.onDelete ( )

Implements com.google.appinventor.components.runtime.Deleteable.

Definition at line 500 of file AccelerometerSensor.java.

◆ onPause()

void com.google.appinventor.components.runtime.AccelerometerSensor.onPause ( )

Implements com.google.appinventor.components.runtime.OnPauseListener.

Definition at line 491 of file AccelerometerSensor.java.

◆ onResume()

void com.google.appinventor.components.runtime.AccelerometerSensor.onResume ( )

Implements com.google.appinventor.components.runtime.OnResumeListener.

Definition at line 482 of file AccelerometerSensor.java.

◆ onSensorChanged()

void com.google.appinventor.components.runtime.AccelerometerSensor.onSensorChanged ( SensorEvent sensorEvent )

Definition at line 455 of file AccelerometerSensor.java.

◆ Sensitivity() [1/2]

int com.google.appinventor.components.runtime.AccelerometerSensor.Sensitivity ( )

Returns a number that encodes how sensitive the AccelerometerSensor is. The choices are: 1 = weak, 2 = moderate, 3 = strong.

Returns: one of Component#ACCELEROMETER_SENSITIVITY_WEAK, Component#ACCELEROMETER_SENSITIVITY_MODERATE or Component#ACCELEROMETER_SENSITIVITY_STRONG

Definition at line 203 of file AccelerometerSensor.java.

◆ Sensitivity() [2/2]

void com.google.appinventor.components.runtime.AccelerometerSensor.Sensitivity ( int sensitivity )

Specifies the sensitivity of the accelerometer. Valid values are: 1 (weak), 2 (moderate), and 3 (strong).

Parameters

sensitivity one of Component#ACCELEROMETER_SENSITIVITY_WEAK, Component#ACCELEROMETER_SENSITIVITY_MODERATE or Component#ACCELEROMETER_SENSITIVITY_STRONG

Definition at line 219 of file AccelerometerSensor.java.

◆ Shaking()

void com.google.appinventor.components.runtime.AccelerometerSensor.Shaking ( )

Indicates the device started being shaken or continues to be shaken.

Definition at line 282 of file AccelerometerSensor.java.

◆ XAccel()

float com.google.appinventor.components.runtime.AccelerometerSensor.XAccel ( )

Returns the acceleration in the X-dimension in SI units (m/s²). The sensor must be enabled to return meaningful values.

Returns: X acceleration

Definition at line 367 of file AccelerometerSensor.java.

◆ YAccel()

float com.google.appinventor.components.runtime.AccelerometerSensor.YAccel ( )

Returns the acceleration in the Y-dimension in SI units (m/s²). The sensor must be enabled to return meaningful values.

Returns: Y acceleration

Definition at line 379 of file AccelerometerSensor.java.

◆ ZAccel()

float com.google.appinventor.components.runtime.AccelerometerSensor.ZAccel ( )

Returns the acceleration in the Z-dimension in SI units (m/s²). The sensor must be enabled to return meaningful values.

Returns: Z acceleration

Definition at line 391 of file AccelerometerSensor.java.

The documentation for this class was generated from the following file:

C:/Users/Ulli/appinventor-sources/appinventor/components/src/com/google/appinventor/components/runtime/AccelerometerSensor.java
